Receiver Radiolink R6DSM Mini, S.BUS/PPM-Serial, 300-600m Range, 15x13x5mm
Receiver Radiolink R6DSM Mini, S.BUS/PPM-Serial, 300-600m Range, for AT9S and AT10II, 15x13x5mm
Receiver is not compatible with Futaba S-FHSS
The Radiolink R6DSM 2.4GHz is an extremely small 10-channel receiver with synchronous DSSS and FHSS frequency hopping transmission. It is particularly suitable for multicopters and race drones. The use of DSSS/FHSS transmission technology offers high interference immunity and the ability to set fail-safe for signal loss or strong interference.
It is compatible with the Radiolink transmitters:
- AT9
- AT 9S
- AT10
- AT10II (must be in 10CH mode)
Operating Modes
- PMM Serial Output:
The red LED indicates PWM signal output, a total of 10 channels. - S-BUS Serial Output:
The blue/purple LED indicates S-BUS signal output, a total of 10 channels.
Binding with the transmitter is done using the bind button on the receiver, and the operating status is indicated by the LED.
The receiver is equipped with contact strips for standard UNI connectors (=JR/Graupner, Hitec, Futaba)
Technical Data:
Modulation/Encoding: 2.4GHz FHSS / DSSS
Channels (S-BUS/PPM): 10
Serial output: PPM, S-BUS
Ground range: 300m
Air range: 600m
Functions: Fail-safe
Power supply: 4.8-6V
Current consumption without servos: 38 - 45mA
Dimensions: 15x13x5mm
Weight: 1.5g
Scope of delivery:
- 1x Receiver R6DSM Mini
- Manual.
