Aeronaut CAM Carbon 12.0"x10.0", # 723449

Why Aeronaut CAMcarbon?

The special features:

The special thing about the new CAM folding propellers is the enormous improvements compared to the classicPROP. This new generation, developed by R. Freudenthaler, has an optimized very thin airfoil design and a computer-calculated blade twist, which leads to very high accuracy with optimal efficiency and low power consumption of the motor.

CAM? What is that...?

CAM is English and stands for "Computer Aided Manufacturing". The molds for the injection molding process are no longer made by hand as with the previous classicPROP, but are developed on a PC with the help of a CAD program (Computer Aided Design). The manufacturing of these molds is then controlled by the PC based on the entered data. This is an enormous advantage, as a more accurate mold can hardly be produced, and the final propeller has practically no deviations from the original model.

The weight:

Convince yourself of the incredibly light weight of the new CAM folding propellers. You will be surprised!

The material:

The material used is exclusively a mixture of carbon fibers with nylon, which gives the propeller high torsional rigidity and has proven itself over many years with our propellers. Carbon is a very strong material, so the propeller retains its shape even under high loads. This is, of course, an advantage over propellers made of fiberglass-reinforced plastic, which achieve different efficiencies under high loads than a CAMcarbon!

The advantages (at a glance):

• Very low weight! Due to the material used and the very thin profiling, the weight is very low.
• A sharp trailing edge! Gives the propeller a special aerodynamic touch.
• Very quiet! The new CAM technology makes these folding propellers among the quietest in their class.
• Very thin profile! Great weight savings, not least because of the material.
• High efficiency! Achieved through the optimal profile.

Technical data:

• Diameter (in inches) 12
• Pitch (in inches) 10
• Blade root width (mm) 8
• Mounting hole (mm) 3
• Permissible RPM (rpm) max. 13000
