Aeronaut CAM Carbon 6"x6"

Why Aeronaut CAMcarbon?

The Special Feature:

The special feature of the new CAM folding propellers are the enormous innovations compared to the classicPROP. This new generation, developed by R. Freudenthaler, has an optimized very thin airfoil design and a computer-calculated airfoil twist, which leads to very high accuracy with optimal efficiency and low power consumption from the motor.

CAM? What is that...?

CAM stands for "Computer Aided Manufacturing." Unlike the classicPROP, where the molds for the injection process were made by hand, they are now developed on a PC using a CAD program (Computer Aided Design). The manufacturing of these molds is then controlled by the PC based on the input data. This is an enormous advantage, as a more precise mold can hardly be produced, and the final propeller has virtually no deviations from the original model.

The Weight:

See for yourself the incredibly light weight of the new CAM folding propellers. You will be surprised!

The Material:

The material used is exclusively a mixture of carbon fibers with nylon, which gives the propeller high torsional rigidity and has proven itself over many years with our propellers. Carbon is a very strong material, so the propeller maintains its shape even under high loads. This is, of course, an advantage over fiberglass-reinforced plastic propellers, which achieve different efficiencies under high loads compared to a CAMcarbon!

The Advantages (at a glance):

• Very low weight! Due to the material used and the very thin profiling, the weight is very low.
• A sharp trailing edge! Gives the propeller a special aerodynamic touch.
• Very quiet! The new CAM technology makes these folding propellers among the quietest in their class.
• Very thin profile! Significant weight savings, not least due to the material.
• High efficiency! Achieved through the optimal profile.

Technical Data:

• Diameter (in inches) 6
• Pitch (in inches) 6
• Blade root width (mm) 6
• Mounting hole (mm) 2
• Permissible RPM (rpm) max. 15000
